Relay RES80-1 DLT4.555.015-03 is sealed, single-stable, two-position, with two changeover contacts. Designed for switching electrical circuits of direct and alternating current.

1. Winding supply current – constant;
2. Winding resistance 1530-1955 ohms;
3. Operate current 7,5 mA;
4. Release current 1,8 mA;
5. Working voltage 24,3-29,7 V;
6. Insulation resistance between current-carrying elements, between current-carrying elements and the case, not less than:
– in normal climatic conditions (the winding is de-energized) 200 MΩ;
– in conditions of high humidity 10 MΩ;
– at maximum temperature (after holding the winding under operating voltage for at least 0.5 h) 20 MΩ;
7. Test alternating voltage between current-carrying elements, between current-carrying elements and the case:
– in normal climatic conditions:
– between current-carrying elements and the case 200 V;
– between current-carrying elements 180 V;
– in conditions of high humidity 150 V;
– at a reduced atmospheric pressure of 150 V.
8. Operating ambient temperature: -60 to +100 °C.
9. Relay Weight: 2.5g.
10. Minimum service life: 20 years.
