RELAYS ELECTROMAGNETIC LOW-CURRENT
RES39 RF4.510.113-01.01
RES39 RF4.510.113-01.01
RELAYS ELECTROMAGNETIC LOW-CURRENT
Available on back-order
Description
Relay RES39 RF4.510.113-01.01 hermetic, two-position, single-stable, with six changeover contacts, powered by direct current, designed for switching DC and AC circuits.
Details
1. The supply current of the winding is constant.
2. Insulation resistance between current-carrying elements, between current-carrying elements and the case, not less than:
– in normal climatic conditions (the winding is de-energized) 200 MΩ.
— at the maximum temperature (after holding the winding under operating voltage) 20 MΩ.
– in conditions of high humidity:
– between contacts, between contacts and case 10 MΩ.
– between the winding and the housing, between the winding and contacts 5 MΩ.
3. Test alternating voltage between current-carrying elements, between current-carrying elements and the case:
– in normal climatic conditions 500 V.
– in conditions of high humidity 300 V.
– at atmospheric pressure 666 250 Pa.
4. Electrical contact resistance is not more than 0.2 ohm.
5. The weight of the relay is not more than 140 g.
