The pump regulator NR-9V is designed to supply fuel to the working injectors of the AI9V-3B engine and to regulate the engine speed. The pump-regulator consists of a centrifugal pump, a speed regulator, a solenoid valve for stopping the engine, speed indicators, and fuel filters. The HP-9V pump is used in the following helicopters: Mi-8 (and its modifications), Mi-14, Mi-17, Mi-17, Mi-172, Mi-24, Mi-35.

1. Working fluid – T-l, TC-1.
2. Operating temperature range -60 .. + 120 ° C.
3. Fuel pressure at the inlet 0.06 .. 0.17 kgf / cm2.
4. Fuel consumption for working injectors is 30-90 kg / h.
5. Rotational speed 38000 … 39500 rpm.
6. Limiting speed 41000 rpm.
7. Weight 3.5 kg.
8. Dimensions 190x180x110 mm.
