ETSNG-40

Description

The ETSNG-40 pump is designed to supply fuel with the necessary pressure to the inlet to the engine boost pump, to transfer fuel from one fuel tank to another, for emergency draining of fuel from tanks and to ensure the operation of jet pumps.

Details

1. Voltage; frequency 200 V; 400 Hz.
2. Delivery 25000/40000 l / h.
3. The pressure drop is 1.5 / 0.8 kgf / cm2.
4. The number of revolutions is 5500 rpm.
5. Current 4.7 A.
6. Weight 8.2 kg.
7. Working fluid – fuel.
8. Dimensions 278×185 mm.
