LAMPS
UV-45
UV-45
LAMPS
Available on back-order
Description
The UV-45 traveling wave tube is designed to operate as a high-frequency power amplifier in the range of 7.4-12 GHz in special-purpose equipment.
It features a high degree of reliability, is used in a wide range of temperatures and high humidity.
Details
1. Operating range 7400 – 12000 MHz.
2. Noise factor, no more than 30 dB.
3. Power gain, not less than 30 dB.
4. Ready time, no more than 1.0 min.
5. Glow current 0.3-0.7 A.
6. Voltage of the retarding system 1050 – 1200 V.
7. Input – waveguide 4×23.
8. Output – waveguide 4×23.
9. Cooling – air.
10. Weight 0.8 kg.
Payment & delivery
All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.
In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.
Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.
Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.
Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.
Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
