Traveling wave lamps UV-435A of continuous operation, packaged, with forced air cooling, are designed to work as microwave power amplifiers in the centimeter range.

1. Operating frequency range 10160-17545 MHz.
2. Input power 200-880uV.
3. Gain 26-30db.
4. Output power 60-90V.
5. Heating voltage 5.85-6.8 V.
6. Glow current 1.4-1.8 A.
7. Cathode voltage 7.0-7.6 kV.
8. The voltage of the retarding system is 7.3-8.2 kV.
9. Collector voltage 3.0-4.0 kV.
10. Weight 2.75 kg.
11. Overall dimensions 370 x 77 x 140 mm.
