The TGI3-500/16 pulsed modulator thyratron is designed for power modulation and switching in radar stations. Filling - hydrogen. Decoration - metal-ceramic.

1. The heating current of the cathode heater is 11-15 A.
2. The heating current of the hydrogen generator is 2.5-4.5 A.
3. Total glow current, no more than 17.5 A.
4. The delay time of the anode current is 0.05-0.3 μs.
5. Intermittent ignition instability, no more than 0.005 μs.
6. Durability, not less than 1000 hours.
7. Filament voltage 6.0-6.6 V.
8. Weight 800 g.
9. Parameters of the ignition pulse of the 2nd grid:
– voltage amplitude, not less than 400 V.
– current in the grid circuit, not less than 3 A.
– pulse duration, not less than 4 μs.
— front rise steepness, not less than 1500 μs.
