TGI2-260/12
TGI2-260/12
LAMPS
Available on back-order
Description
The TGI2-260/12 pulse modulator thyratron is designed for switching in a linear modulator circuit. Produced in glass design.
Socle special, 4-pin. The balloon is filled with hydrogen. Cathode oxide, indirect heating. Warm-up time 3 min. Works in any position provided that the thyratron is attached to the flask.
Details
1. Heating voltage 12 V.
2. Heating current 260 A.
3. Periodic instability of ignition at the steepness of the rise of the grid pulse, not less than 600 V/µs, not more than 0.004 µs.
4. Change in the delay time of the anode current with respect to the voltage pulse on the grid when the filament voltage changes from 6 to 6.6 V, no more than 0.07 μs.
5. Ignition characteristic – positive.
6. Ambient temperature from -60 to +90° С.
7. Cooling – natural.
8. Service life – at least 250 hours.
9. Weight – no more than 650 g.
Payment & delivery
All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.
In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.
Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.
Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.
Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.
Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
