LAMPS
GU-81M
GU-81M
LAMPS
Available on back-order
Description
Generator pentode GU-81M for operation as an amplifier of high-frequency oscillations at frequencies up to 50 MHz. Cathode - tungsten thoriated carbide direct heating. Decoration - glass with a plinth. Working position - vertical, balloon up.
Cooling is natural.
Details
1. Heating current, no more than 10.5 A.
2. The current of the 1st grid is reversed (at Un=13.6 V, Ua=3 kV), not more than 50 μA.
3. Permeability of the 1st grid relative to the 2nd grid (at Uс2=0.5 and 0.6 kV) 31.5 ± 4.5%.
4. The steepness of the characteristic (when Uc changes by 10 V) 5.5 ± 1 mA / V.
5. Vibrational power:
– at a frequency of 50 MHz at Uc1=200 V, Ia=600 mA, Ic2=200 mA, not less than 400 W.
– at a frequency of 12 MHz with Ua=1.5 kV, Ia=500 mA, not less than 750 W.
6. Interelectrode capacitances:
– grids – cathode 28.5 ± 3.5 pF.
– anode – cathode 23.5 ± 2.5 pF.
– 1st mesh – anode, no more than 0.1.
– 1st grid – 3rd grid, 4.0 ± 1.5.
7. Durability, not less than 1000 hours.
8. Heating voltage 11.8 – 13.5 V.
Payment & delivery
All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.
In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.
Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.
Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.
Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.
Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
