GU-78B
GU-78B
LAMPS
Available on back-order
Description
The generator tetrode GU-78B is designed to amplify high-frequency oscillations in amplifiers of a single-sideband signal with a power of up to 2.5 kW at frequencies up to 250 MHz. Cathode-oxide indirect heating. Decoration - metal-ceramic.
Cooling - forced air not less than 280 m3/h.
Details
1. Heating voltage 27 V.
2. Glow current 3.4-4.0 A.
3. Anode voltage 1.7 kV.
4. Voltage of the 2nd grid 300 V.
5. Bias voltage of the 1st grid, negative 51 V.
6. Locking voltage (at Ua=3 kV; la=20 mA), negative, not more than 150 V.
7. Anode current 1.5A.
8. Zero anode current (at Ua=250 V; Uc1=0 V), not less than 4.2 A.
9. The current of the 2nd grid is zero (at Ua=250 V; Uc1=0 V), not more than 0.9 mA.
10. Slope 60 ± 20mA/V.
11. Output power in class AB1 mode (at Un=27 V) 2.5 kW.
12. Output power in class AB1 mode (at Un=25.7 V) 2.2 kW.
13. Interelectrode capacitances:
– input 100-150 pF,
– output 15-30 pF,
– through passage, no more than 0.25 pF.
14. Heating voltage 25.7-28.3 V.
15. Durability – not less than 1000 hours.
16. Weight – 1.8 kg.
