GU-62A
GU-62A
LAMPS
Available on back-order
Description
Generator triode GU-62A for operation in amplifiers - generators of high-frequency oscillations.
Decoration - glass-metal. Working position - vertical, anode down.
Cooling - forced:
- anode - water at least 50 l / min.
— legs — air not less than 40 m3/h.
- cylinder and metal-to-glass junctions - air at least 400 m3/h.
Details
1. Filament current 120 ± 15 A.
2. Reverse grid current (at Ua=10 kV, Ia=3 A), not more than 100 μA.
3. Cathode emission current (at Ua=0.5 kV, Un=10.8 V), not less than 25 A.
4. The steepness of the characteristic (at Ia=10 and 12.5 A) 60 ± 10 mA/V.
5. Gain 23 ± 4.
6. Grid blocking voltage, negative, not more than 420 V.
7.Output power:
– at a frequency of 85 MHz (at Ua = 7.5 – 8 kV), not less than 40 kW,
– at a frequency of 440 MHz (at Ua \u003d 10 – 10.5 kV), not less than 63 kW.
8. Interelectrode capacitances:
– input, no more than 80 pF,
– output, no more than 2.8 pF,
– pass-through, no more than 60 pF.
9. Heating voltage 10.8 – 12.6 V.
10. Durability, not less than 2000 hours.
