GU-5B
GU-5B
LAMPS
Available on back-order
Description
The generator triode GU-5B is designed to amplify power at frequencies up to 110 MHz in various radio engineering devices and to operate in high-frequency heating generators.
Cathode - tungsten thoriated carbide direct heating. Cooling - forced air.
Execution - glass-to-metal.
Details
1. Glow current 23 A.
2. Reverse grid current, not more than 20 μA.
3. Cathode emission current (at Ua=Uc=500 V), not less than 6 A.
4. Ionic anode current (at Ua=500 V), not more than 40 μA.
5. Anode current (at Uс=0 V) 0.55 ± 10 A.
6. Slope 15 ± 3mA/V.
7. Gain (at Ia=0.5 A, Ua=2 and 4 kV) 72.5 ± 12.5.
8. Output power (at a frequency of 25 MHz), not less than 3.5 kW.
8. Weight – no more than 2.5 kg.
9. Interelectrode capacitances:
– input, no more than 19 pF,
– output, no more than 16 pF,
– through passage, no more than 0.5 pF.
10. Durability, not less than 1000 hours.
11. Heating voltage 12.6 V.
12. Power dissipated by the anode 2.5 kW.
13. Operating ambient temperature range from -60 to +70 C.
