Powerful generator triode GU-58B for generating high-frequency oscillations up to 300 MHz in industrial generators for high-frequency heating. Decoration - glass-metal.
Working position - vertical, glass bottle up.
Cooling - forced:
— anode — air not less than 550 m3/h.
- cylinder - air at least 30 m3 / h.
— legs — air not less than 50 m3/h.

1. Heating current, no more than 64 A.
2. Anode current (at Ua=400 V, Uc=150 V), not less than 2.9 A.
3. Anode current (at Uc1=0), not less than 1 A.
4. Steepness of the characteristic, not less than 22 mA/V.
5. Gain, not less than 33.
6. Grid voltage blocking negative (at Ua=3 kV, Ik=0.1 A), no more than 130 V.
7. Output power, not less than 2.5 kW.
8. Weight not more than 3.5 kg.
9. Interelectrode capacitances:
– grid – cathode, no more than 40 pF,
– anode – cathode, no more than 0.1 pF,
– grid – anode, no more than 20 pF.
10. Durability, not less than 1000 hours.
11. Heating voltage 5.7 – 6.3 V.
12. Power dissipated by the anode 4 kW.
13. Operating ambient temperature range from +20 to +50 C.
