Powerful oscillator tetrodes for operation as high-frequency oscillation amplifiers in the single-sideband amplification mode at frequencies up to 70 MHz. Decoration - metal-ceramic. Working position - vertical, anode down. Cooling is forced.

1. Heating current 245±15A.
2. Anode current at Uc1 = 0 ≥16 mA.
3. Current of the second grid at Ua = 1.1 kV ≤1.3 mA.
4. Cathode emission current at Ua = Uc1 = Uc2 = 400 V ≥55 mA.
5. The current of the first grid is reverse at Ua = 3 kV; Uc2 = 1.5 kV ≤150.
6. Blocking voltage of the first grid at Ua = 10 kV; Uc2 = 1.5 kV; Ia = 0.5A ≤-350V.
7. The steepness of the characteristic 125±15.
8. The gain of the first grid relative to the second grid is 8.5±1.5.
9. Output power at 60MHz:
— at Ua = 12 kV ≥80 kW.
at 60 MHz:
— at Ua = 10 kV ≥50 kW.
10. Operating hours ≥1000.
14. Weight – no more than 33 kg.
