Powerful generator triode GU-23A with a tungsten thoriated, carbide directly heated cathode and water-cooled anode.
Designed to work as an amplifier or generator of high-frequency oscillations at frequencies up to 30 MHz in radio transmitters and industrial generators for high-frequency heating.
Decoration: glass-metal.
Operating position: vertical, anode down.
Forced cooling:
- anode - water at least 120 l / min;
- channel outlets - water at least 2.5 l / min;
- mesh output - water at least 2.5 l / min;
— legs — air not less than 80 m3/h;
- cylinder - air at least 100m3 / h.

1. Filament current 210 ± 15 A.
2. Anode current (at Ua=8 kV, Uc=0) 3.5 (+8; -6) A.
3. Ionic anode current (at Uа= -0.5 kV) ≤ 150 μA.
4. Grid reverse current (at Uc= -300 V, Ua=0) ≤ 300 μA.
5. Cathode emission current (at Uа=Uс=1.3 kV) 60 ± 7.5 A.
6. Slope 48.5 ± 7.5 mA/V.
7. Gain 50 ± 8.
8. Interelectrode capacitances:
– input ≤ 100 pF,
– output ≤ 65 pF,
– throughput ≤ 2 pF.
9. Weight of the triode: 11 kg.
10. Heating voltage 12 V.
11. Power dissipated by the anode 50 kW.
12. Operating ambient temperature range from 5 to +70 °C.
13. Durability average ≥ 1500 h.
