Ceramic-metal generator tetrode GS-36B. Designed for power amplification at frequencies up to 500 MHz in amplifiers with distributed amplification and in single-sideband signal amplifiers at frequencies up to 75 MHz.

1. Heating voltage (AC or DC) 6.3 V.

2. Glow current 2.95-3.35 A.

3. Slope 20-24mA/V.

3. Output power, not less than 200 watts.

4. Interelectrode capacitances:

– input 18 … 30 pF,

– output no more than 5 … 9 pF,

– throughput not more than 0.08 pF.

5. Heating voltage 6 … 6.6 V.

6. Operating frequency 500MHz.

7. Weight – no more than 220 g.

8. Durability not less than 1000 hours.
