The GS-35B high-frequency triode is designed to generate oscillations in self-oscillators with external feedback and power amplification in continuous mode in circuits with a common grid at frequencies up to 1000 MHz. Decoration - metal-ceramic. Cooling - air.

1. Filament current 2.95 ± 0.3 A.

2. The cathode emission current in a pulse (at Ua=600 V), not less than 15 A.

3. Grid voltage at the operating point, not less than 9 ±3 V.

4. The steepness of the characteristic (at Uc1=1 V), not less than 30 mA/V.

5. Permeability (at Ua=-200 V), not less than 1 ±0.2%.

6. Useful power, not less than 350 watts.

7. Interelectrode capacitances:

– input 21 ± 3 pF,

– output no more than 0.12 pF,

– through passage 4.5 ± 0.7 pF.

8. Heating voltage 11.9 … 13.3 V.

9. Ambient operating temperature range
from -60 to +100 C.

10. Weight – 2.8 kg.

11. Durability – not less than 500 hours.
