LAMPS
GS-31B
GS-31B
LAMPS
Available on back-order
Description
Metal-ceramic generator triode. Designed to generate and amplify oscillations in the decimeter and meter wave ranges in continuous mode in circuits with a common grid. The design is metal-ceramic, with cylindrical electrode leads.
Details
1. Filament current 3.4 ± 0.3 A.
2. The cathode emission current in a pulse (at Ua=Uc=600 V), not less than 8 A.
3. The voltage at the operating point is negative 9 ± 3 V.
4. The steepness of the characteristic (when Uс changes by 1 V), not less than 22 mA/V.
5. Ready time no more than 120 s.
6. Net continuous power:
— at l=60 cm, Ua=1.8 kV, Ia=500 mA, not less than 360 W,
— at l=30 cm, Ua=1.7 kV, Ia=700 mA, not less than 180 W.
7. Interelectrode capacitances:
– input 21.5 ± 2.5 pF,
– output no more than 0.12 pF,
– through passage 4.5 ± 0.7 pF.
8. Heating voltage 12 – 13.2 V.
9. Ambient operating temperature range
from -60 to +70 С.
10. Weight no more than 1.2 kg.
11. Durability, not less than 1000 hours.
