Generator triode GS-30 for generating and amplifying oscillations in the centimeter frequency range in circuits with a common grid. The design is titanium-ceramic, with cylindrical electrode leads.

1. Filament current 1 ± 0.2 A.

2. The voltage at the operating point is negative 6.5 ± 1.5 V.

3. The steepness of the characteristic (at Uа=450 V, Iа=50 mA), not less than 20 mA/V.

4. Ready time, not less than 60 s.

5. Vibrational power in continuous mode ( l=30 cm), not less than 20 watts.

6. Current of the 2nd grid (at Ua=1 kV, Uc2= 0.6 kV), not less than 0.4 A.

7. Interelectrode capacitances:
– input 11 ± 2 pF,

– output no more than 0.05 pF,

– throughput 2.8 pF.

8. Heating voltage 6 – 6.6 V.

9. Ambient operating temperature range
from -65 to +125 C.

10. Weight 30 g.

11. Durability, not less than 1000 hours.
