Ceramic-metal generator tetrode.
Designed to generate and amplify high-frequency oscillations in continuous mode in circuits with a common grid.
Durability - not less than 2000 hours.
Shelf life: 12 years.

1. Filament current 2.28 A.

2. The current of the 1st grid is reverse, not more than 20 μA.

3. The voltage of the 1st grid at the operating point is negative, 10 V.

4. The steepness of the characteristic (at Uc=1 V), not less than 9 mA/V.

5. Vibrational power in amplification mode (Uа=1.5 kV, Uс2=300 V, l=30 cm), not less than 160 W.

6. Power dissipated by the anode 200W.

7. Excitation power 12W.

8. Interelectrode capacitances:
– 1st grid – cathode 8 pF,

– 2nd grid – anode 1.8 pF.

8. Heating voltage 6 – 6.6 V.

9. Ambient operating temperature range
from -60 to +100 C.

10. Weight no more than 140 g.
