GMI-46B
GMI-46B
LAMPS
Available on back-order
Description
Pulse modulator triode GMI-46B with a protective grid in ceramic-metal design with indirectly heated oxide cathode and external anode with forced air cooling is designed for switching pulsed power in pulsed modulators of stationary and mobile equipment.
Details
1. Anode current in a pulse – not less than 50 A.
2. The anode current in a pulse at a low temperature (U=24.2 V) is not less than 43 A.
3. Grid current per pulse – no more than 0.15 A.
4. The locking voltage is negative – no more than 200 V.
5. Glow current – from 7.6 to 8.4 A.
6. Reverse grid current – no more than 500 μA.
7. Anode current in a pulse at a short time, not less than: – with an operating time of up to 500 hours (inclusive) – 35 A – with an operating time of more than 500 hours up to 3000 hours – 28 A.
8. Grid current per pulse, not more than 0.3 anode current per pulse.
9. Heating voltage (variable or constant) – from 24.7 to 27.3 V.
10. Sheath temperature: – anode – no more than 150 C – legs – no more than 160 C.
Payment & delivery
All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.
In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.
Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.
Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.
Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.
Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
