Glass-to-metal generator triode.
Designed to amplify the power of high-frequency oscillations in radio engineering devices for a wide range of applications. Decoration - glass-metal. Working position - vertical, anode down. Durability not less than 2000 hours. Weight not more than 12 kg.
Cooling - forced:
— anode — air not less than 1300 m3/h,
— legs — air not less than 30 m3/h.

1. Filament current 135 ± 15 A.
2. Stability of the anode current for 10 minutes (at Ua=1 kV), not less than 0.3 A.
3. Reverse grid current (at Ua=8 kV and Uc=200 V), not more than 440 μA.
4. Reverse grid current (at Ua=0.8 kV and Uc=200 V), not more than 340 μA.
5. Ionic grid current, not more than 100 μA.
6. Emission current in a pulse (at Un=7.9 V and Ua=1 kV), not less than 40 A.
7. Leakage current between the grid and the cathode (at Usk=200 V), not more than 300 μA.
8. Slope 50 ± 8 mA/V.
9. Gain (at Ua=4.8 kV and Ia=2.5 A) 28 ± 4.
10. Grid voltage locking negative, no more than 420 V.
11. Vibrational power (at a frequency of 2 MHz), not less than 30 kW.
12. Interelectrode capacitances:
– grid-cathode, no more than 80 pF,
— anode-cathode, no more than 2 pF,
– grid-anode, not more than 50 pF.
13. Heating voltage 7.9-8.7 V.
14. Operating ambient temperature range from -60 to +70 °C.
