Powerful generator triode - GK-5A lamp for amplifying and generating high-frequency oscillations in radio transmitting devices and in industrial generators for high-frequency heating. Decoration - glass-metal. Working position - vertical, anode down.

1. Heating voltage (AC or DC) 17 V.
2. Heating current 540-610 A.
3. The steepness of the characteristic (at an anode voltage of 10 kV, anode currents of 6 and 8 A) 70-110 mA/V.
4. Gain (at anode voltages of 8 and 10 kV, anode current of 6 A) 32-48.
5. Interelectrode capacities, not more than:
– input 220pF,
– output 5pF,
– throughput 100 pF.
6. Operating frequency 22MHz.
7. The temperature of the sheath and junctions is 150°C.
8.Weight 19kg.
