GI-7BT
GI-7BT
LAMPS
Available on back-order
Description
Pulse generator triode GI-7BT for generating and amplifying high-frequency oscillations of the decimeter range in continuous operation and in pulsed anode modulation. Decoration - metal-ceramic. Cooling - forced - air not less than 24 m3/h. Weight - 330 g.
Details
1. Filament current 1.925 ± 0.125 A.
2. Anode current at the beginning of the characteristic (at Ua=1.5 kV, Uc= -40 V), not more than 5 mA.
3. Reverse grid current (at Ua=1.5 kV), not more than 50 μA.
4. Emission current in a pulse (at Ua=Uc=400 V), not less than 20 A.
5. Leakage current grid – cathode (at Uc = -200 V) 40 – 80 A.
6. Slope 23 ± 3mA/V.
7. Permeability (when Ua changes by 200 V) 1.5 ± 0.3%.
8. Operating point voltage (negative) 10±2.5V.
9. Oscillatory power in pulsed mode, not less than 12 W.
10. Interelectrode capacitances:
– input 11.1 ± 1.1 pF,
– output 4.6 ± 0.4 pF,
– through passage 0.075 ± 0.02 pF.
11. Heating voltage 12-13.2 V.
12. Operating ambient temperature range from -60 to +70 C.
