Powerful pulse generator triode GI-5B for generating high-frequency oscillations in the frequency range up to 200 MHz in circuits with a common grid in self-excitation mode with pulse anode modulation. The design is metal-glass. Working position - vertical, anode down, or horizontal.

1. Heater current 425 ± 40 A.

2. Anode current (at Uа = 3 kV) 1.15 ± 3.5 A.

3. The emission current of the cathode in a pulse (at Uа = Us = 4 kV) 250 A.

4. Reverse grid current (at Uс1 = -300 V), no more than 400 μA.

5. The slope of the characteristic is 25 ± 5 mA / V.

6. Gain 35 ± 5.

7. Output power in a pulse, not less than 1200 kW.

8. Interelectrode capacities:
– input, no more than 90 pF,

– output, no more than 35 pF,

– checkpoint, no more than 13 pF.

9. Heater voltage 6-6.6 V.

10. The range of ambient operating temperatures is from -50 to +60 C.
