Pulse generator triode GI-31 for operation as a generator of high-frequency oscillations in the decimeter and centimeter ranges with pulse anode modulation. Design - metal-ceramic. Weight 18 g.

1. Heater current 0.95 ± 0.05 A.

2. The grid current is reverse (at Uс1 = 2 V), no more than 2 μA.

3. Slope of characteristics, not less than 15 mA / V.

4. The voltage at the operating point is negative 2.5 V.

5. Oscillatory power per pulse is not less than 1500 W.

6. Blocking voltage 1st negative 55 V.

7. Interelectrode capacities:

– no more than 5 pF,

– no more than 0.04 pF,

– no more than 2.7 pF.

8. Heater voltage 6 – 6.6 V.

9. The power dissipated by the anode is 10 W.

10. The range of working ambient temperatures is from -60 to +100 C.
