Pulse generator triode GI-23B for generating and amplifying high-frequency oscillations in a pulsed mode of operation with anodic modulation in the decimeter wavelength range. Design - metal-ceramic. Cooling - forced air 24 m3 / h. Weight - 380 g.

1. Filament current 2.45 ± 0.15 A.

2. The grid current is reverse 155 ± 45 mA.

3. The slope of the characteristic is 31 ± 5 mA / V.

4. The grid current is reverse, no more than 50 µA.

5. Permeability 1.5 ± 0.5%.

6. Net power in a pulse, not less than 40 kW.

7. Interelectrode capacities:

– input 16 ± 2 pF,

– output, no more than 0.16 pF,

– pass 6 ± 0.5 pF.

8. Heater voltage 11.9 – 13.3 V.

9. The power dissipated by the anode is 300 W.

10. The range of working ambient temperatures is from -60 to +100 C.
