LAMPS
DKSSHRB-5000-1
DKSSHRB-5000-1
LAMPS
Available on back-order
Description
Dismountable xenon spherical arc lamp type DKSSHRB-5000-1, designed to work in projection equipment. Type of climatic version UHL 4.2. The lamp is made in the form of a spherical quartz cylinder with two opposite electrodes, cooled from the inside with water. The more massive electrode is the anode. The bulb of the lamp is filled with xenon to a pressure above atmospheric. Lamps have intense continuous radiation in the ultraviolet, visible and near infrared regions of the spectrum. In the infrared region, in addition to continuous radiation, there is intense line radiation in the wavelength range from 800 to 1000 nm.
Details
1. Light center height: 101.
2. Overall package dimensions: 0.5×0.5×0.5 m.
3. Flask diameter: no more than 55 mm.
4. Lamp length: 230±5mm.
5. Protective case: metal.
6. Maximum burning time: 500 hours.
7. Power: nominal. 5000 W.
8. Voltage: not less than 31V.
9. Ignition voltage: 70V.
10. Distance between electrodes: not less than 5 mm, not more than 6 mm.
11. Luminous flux after 400 hours of burning: at least 150 km.
12. Luminous flux: not less than 190 km.
13. Average burning time: 400 hours.
14. Lamp current: no more than 160 A.
15. Brightness: not less than 700 Mcd/m2.
Payment & delivery
All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.
In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.
Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.
Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.
Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.
Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
