Lamp 6Ts4P-EV is a two-anode kenotron with an indirectly heated oxide cathode of increased durability, reliability and mechanical strength. Designed for rectifying alternating current of industrial frequency 50 Hz. Durability not less than 5000 hours. Weight not more than 15 g.

1. Heater voltage 6.3 ± 0.6 V.
2. Heater current 600 ± 60 A.
3. Voltage at the anode 1000 V.
4. Limiting anode current (peak value) 300 mA.
5. Rectified rated current not less than 72 mA.
6. Rectified current limiting 75 mA.
7. The power dissipated by the anode is 3 W.
8. The voltage between the cathode and the heater is limiting (constant) 400 V.
9. The voltage of the secondary winding of the transformer is 2×350 V.
10. Resistance in the cathode circuit 5200 Ohm.
11. The filter capacity is 8 μF.
12. Design – miniature glass.
