LAMPS
6P1P-EV
6P1P-EV
LAMPS
Available on back-order
Description
The 6P1P-EV lamp is a miniature output beam tetrode with increased durability, reliability and mechanical strength. Designed to amplify low frequency power. Durability not less than 5000 hours. Weight not more than 20 g.
Details
1. Heater voltage 6.3 ± 0.6 V.
2. Filament current 500 ± 40 mA.
3. Nominal anode voltage (constant) 250 V.
4. The anode voltage limit (constant) 250 V.
5. Anode current 44 ± 11 mA.
6. Cathode current (peak value) 70 mA.
7. The second grid voltage is rated (constant) 250 V.
8. The second limit grid voltage (constant) 250 V.
9. The second grid current is not more than 7 mA.
10. Power dissipated by the anode, limiting 12 watts.
11. The power dissipated by the second grid is 2.5 watts.
12. The voltage between the cathode and the heater is limiting (constant) 100 V.
13. The slope of the characteristic is 4.9 ± 1.1 mA / V.
14. Coefficient of nonlinear distortion 14%.
15. Resistance in the first grid circuit is limiting 42.5 ± 22.5 kOhm.
16. The input capacitance is 9.5 pF.
17. Output capacitance 7 pF.
18. Capacity through passage, no more than 5.4 pF.
19. Design – miniature glass.
