The MGV-1 vertical gyro is a two-gyro platform with power stabilization. Designed to determine the spatial position of an aircraft or helicopter relative to the horizon and are roll and pitch angle sensors, which are issued to consumers in the form of electrical signals. Small-sized vertical gyro MGV-1 is used on TU-154, An-72, An-74, Yak-42, Mi-26, Ka-32 helicopters.

1. Supply voltage:

– DC 27 + 2.7V,

– alternating current of frequency 400 + 8 Hz 36 (+1.8; -3.6) V;

2. Ready time, no more than 4 minutes;

3. Accuracy of bringing to the vertical from the arresting device +2 deg .;

4. Consumed alternating current in a phase, no more than 0.8 A;

5. The error of keeping the vertical on a fixed base, no more than +5 arc. min .;

6. The error of keeping the vertical on a swinging base, no more than +15 arc. min .;

7. Recovery time for inclinations of 5 ° from 2.5 to 7 minutes;

8. Limiting working angles, degrees:

– on the roll +180,

– pitch +60;

9. Weight, no more than 5.6 kg.
