Сargo winch
LPG-300
LPG-300
Сargo winch
Available on back-order
Description
The LPG-300 helicopter hoist system is designed for lifting and lowering loads up to 300 kg, as well as safely deploying or retrieving up to two people when landing in hover mode is not possible. The system operates at heights up to 50 m and features a smooth four-speed control mode for precise and reliable handling.
Details
Type: Helicopter cargo and rescue hoist
Model: LPG-300
Lifting Capacity (Operational): up to 200 kg
Lifting Capacity (Ground): up to 300 kg
Rated Load on Rope: 2940 N (300 kgf)
Rope Length: 60 m
Rope Diameter: 5 mm
Power Supply
DC: 27 V
AC: 200 V, 400 Hz
Load Movement Speed
Rope release: 2 m/s
Rope release (low speed): 0.5 m/s
Rope retrieval (max): 1.4 m/s
Rope retrieval (min): 0.3 m/s
Rope Harvesting Speed
At 1470 N (150 kgf): 60 m/min
At 1960 N (200 kgf): 5 m/min
System Dimensions: 470 × 410 × 340 mm
System Weight: ≤ 78.25 kg
Application: Helicopter cargo operations, personnel lifting, rescue missions up to 50 m height
Payment & delivery
All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.
In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.
Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.
Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.
Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.
Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
