The portable pumping unit PNA-1M 8D2-960-000 is designed for refueling yachts, water transport, agricultural machinery, helicopters, aircraft from barrels, tanks and other containers. Has built-in coarse and fine filter elements.

1. Working environment TS-1, T-1, T-2, gasoline B-70, B-91/115, B-95/130, B-100/130.
2. Voltage 27 ± 2 V.
3. Duration of continuous operation of the unit, no more than 3 hours.
4. Filtration fineness 10 microns.
5. Altitude from sea level, no more than 2000 m.
6. Productivity of the unit at a suction height of the working medium of 1 m and a discharge height of 3.5 m, not less than 4000 l / h.
7. Temperature range of working and environment – 50 … +50 ° С.
8. Unit weight without sleeves, no more than 15 kg.
