The oscillating frequency generator GKCH61 is intended for use as a microwave signal source as part of a panoramic voltage standing wave ratio (VSWR) meter of the P2 type.

1. Ambient temperature – from 278K to 313K (from 5 ° C to 40 ° C);
2. Relative air humidity – up to 95% at a temperature of 303K (30 ° C);
3. The frequency range of the device oscillating frequency generator – 8.15GHz-12.05GHz;
4. Power supply – 220V ± 22V, 50Hz ± 0.5Hz;
5. The maximum permissible basic error in determining the frequency and boundary frequencies of the oscillation band does not exceed ± 0.02f, where f is the value of the maximum frequency of the operating subband;
6. The short-term frequency instability of the device, the GKCH61 sweeping frequency generator in the RFC mode, within 5 minutes and after 5 minutes after the frequency tuning does not exceed 1 ∙ 10-3f under normal conditions;
7. The width of the spectrum of the output signal in the LH and RFC mode, taking into account the parasitic frequency deviation at the level of –10 dB from the level of the main signal, does not exceed 0.05f, where f is the minimum frequency oscillation band;
8. The time of continuous operation does not include the time of establishing the working mode;
9. Overall dimensions of the device, the oscillating frequency generator – 490 x 475 x 175mm;
10. Weight – 90kg.
