The main principle and goal of Aviamisto has always been the high quality of products and services, as well as their prompt delivery to customers.

1. Fineness of a filtration is 200 microns.
3. Working environment – jet fuel.
4. Nominal pressure of the working medium 4.5 (45) MPa (kgf/cm2).
5. Rated flow rate 835L/min.
6. Hydraulic resistance of a clean filter at a maximum throughput of 1110 l/min, no more than 0.06 (0.6) MPa (kgf/cm2).
7. Temperature range – 50 … + 150 ° С (environment / working fluid).
8. Pressure drop across the filter element at which the bypass valve opens 0.08 +0.002 (0.8 +0.2) MPa (kgf/cm2).
9. Pressure drop across the filter element, at which the alarm is triggered 0.04 ±0.01 (0.4 ±0.1) MPa (kgf/cm2).
10. Dry filter weight, no more than 2.2 kg.
11. Signaling device DC voltage 27 ±3 V.
