The VK 315 fan is an inline centrifugal fan. This fan provides a maximum air capacity of up to 1340 m3 / h, an operating pressure of up to 500 Pa. The fan is designed for installation in duct supply and exhaust ventilation systems with a diameter of 315 mm. The use of engineering plastic in the construction of the fan allows it to be used in rooms with high humidity, where the use of metal fans is impossible due to corrosion.

1. Voltage 230 V;
2. The frequency of the current is 50 Hz;
3. Maximum power 200 W;
4. Productivity is 1340 m3 / h;
5. Current 0.88 A;
6. Rotation speed 2655 min-1;
7. Noise level at a distance of 3 m 50 dB (A);
8. Maximum temperature of transported air -25 … + 50 С;
9. Weight 5.1 kg;
10. Protection IPX4 class;
11.The size of the nozzle is 315 mm.
