High-frequency axial electric fan EV-2-366 is designed for cooling radio-electronic equipment, designed for power supply from a three-phase alternating current network with a frequency of 400 Hz. The operating mode is long-term. Any position in space.

1. Nominal capacity 200 m3 / h;
2. Full pressure at rated performance 500 (50) Pa (kgf / m2);
3. Supply voltage 200 V;
4. The frequency of the supply voltage is 400 Hz;
5. The number of phases of the supply network is 3;
6. Power consumption, no more than 95 W;
7. Consumption current, no more than 0.37 A;
8. Rotation frequency, not less than 10200 min-1;
9. Sound level, no more than 79 dBA;
10. Weight, no more than 0.43 kg;
11. Guaranteed operating time 3000 hours.
12. Ambient temperature during operation from -60 to +100 C.
13. Operating mode – long-term.

All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.

In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.

Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.

Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.

Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.

Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
