Hydraulic Valve
GA-192
GA-192
$1350
Hydraulic Valve
Description
The GA-192 is an aircraft electromagnetic hydraulic valve designed for remote control of hydraulic units in onboard hydraulic systems.
Within the hydraulic system, the valve provides controlled supply and shutoff of hydraulic fluid to actuating units, enabling operation of hydraulic boosters and auxiliary hydraulic mechanisms.
The valve is used in hydraulic systems of helicopters and aircraft, where electrically controlled switching of hydraulic circuits is required for normal and combined operating modes.
The product is also known under alternative designations GA-192, ГА-192, which refer to the same product type.
Details
Product Type: Electromagnetic hydraulic valve
Function: Remote control of hydraulic fluid supply
Application / Where Used: Aircraft hydraulic systems
System / Installation Area: Hydraulic control and auxiliary circuits
Compatible Aircraft / Equipment: Mi-8, An-8, An-12, Yak-40, An-10, Yak-38, Tu-134
Working Medium: AMG-10
Operating Temperature Range: −60 to +80 °C
Operating Pressure: 150 (+15 / −2) kgf/cm²
Maximum Operating Pressure (Emergency): 180 ± 8 kgf/cm²
Permissible Back Pressure in Drain Line: Not more than 20 kgf/cm²
Hydraulic Resistance at 12 L/min and 20 °C: Not more than 10 kgf/cm²
Operating Voltage: 27 ± 10 V
Current Consumption: Not more than 1.2 A
Electromagnet Response Time: Not more than 0.1 s
Dimensions: 213 × 88 × 44 mm
Weight: Not more than 1.0 kg
Technical Documentation: GA-192 Technical Description and Operating Documentation
Payment & delivery
All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.
In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.
Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.
Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.
Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.
Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
