Current collector TSV-36M-313 is designed to transmit electricity to the heating elements of the anti-icing system of the rotor propellers, circuit lamps, metallization between the shaft and the engine housing. Used in helicopters.

1. The frequency of the current is 400 ± 20 Hz.
2. Supply voltage DC 27 ± 2.7 V.
3. Rated load current of three-phase alternating current Phase B 125, phase A and C 90 A.
4. Rated load current of alternating single-phase current, no more than 6 A.
5. Rated load current in control and monitoring circuits, no more than 3 A.
6. The frequency of rotation of the body is 246 rpm.
7. The transmitted voltage of alternating three-phase current is 208 ± 10.4 V.
8. The transmitted voltage of an alternating single-phase current is 7.5 ± 0.75 V.
9. Product weight, no more than 25.3 kg.
10. Dimensions 420x404x404 mm.
