Current collector TS-5TV is designed to transmit single-phase alternating current power to the propeller and fairing anti-icing system, as well as to provide metallization between the shaft and the body of the object. It is used on airplanes.

1. Supply voltage of alternating current 115 ± 11.5 V.
2. The frequency of the current is 400 Hz.
3. Current strength, no more than 70 A.
4. The transmitted power is 8 kW.
5. The frequency of rotation of the slip rings is 1100 rpm.
6. Overall dimensions of the contact ring 75x350x350 mm.
7. Overall dimensions of one box of brush holders 225x135x95 mm.
8. Overall dimensions of one brush holder 115x55x25 mm.
9. Product weight, no more than 7.5 kg.
